Technicial Specifications
TECHNICAL DATA MDC 3-4 MDC 5-6 MDC 7-8 MDC 9-10 Total number of disc adet/pcs. 3/4 5/6 7/8 9/10 Disc diameter mm 350 350 350 350 Min./Max. cutting width mm 215/3100 215/3100 215/3100 215/3100 Min./Max. cutting thickness mm 0-70 0-70 0-70 0-70 Conveyor belt motor power kw/hp 3/4 3/4 3/4 3/4 Bridge forward-backward movement motor power kw/hp 1.5/2 1.5/2 1.5/2 1.5/2 Disc motor power kw/hp 7.5/11 7.5/11 7.5/11 7.5/11 Overall dimensions (Length x Width x Height) mm 5700 x 2310 x 2200 5700 x 2310 x 2200 5700 x 2310 x 2200 5700 x 2310 x 2200 Total electric power kw/hp 27/36-35/47 42/56-50/67 57.5/83-64.5/94 72/105-79.5/110 Machine weight kg 7200-7500 7400-7500 7600-7700 7800-7900
Since 1978, we are proud of the rightful trust in our machines that have been working successfully in the country and in the world, and we are in an effort to offer you quality.
