Technicial Specifications
TECHNICAL DATA OPCM 8-10 OPCM 12-14 OPCM 16-18 OPCM 20-22 Number of heads pcs. 8-10 12-14 16-18 20-22 Granite head diameter mm 520 520 520 520 Marble plate diameter mm 580 580 580 580 Number of abrasives for granite head pcs. 6 6 6 6 Number of abrasives for marble plate pcs. 8 8 8 8 Working width mm 2200 2200 2200 2200 Working thickness mm 20-100* 20-100* 20-100* 20-100* Belt width mm 2320 2320 2320 2320 Belt motor power kw 4 4 4 4 Calibrating head motor power kw 18,5 18,5 18,5 18,5 Polishing head motor power kw 15 15 15 15 Bridge motor power kw 7.5x2 7.5x2 7.5x2+7.5x2 7.5x2+7.5x2 Machine width & height mm 3650x2450 3650x2450 3650x2450 3650x2450 Machine length mm 9520/10690 12160/13340 15930/17110 18290/19470 Total electric power kw 168/205 221/251 296/326 356/386 Total water necessity lit./min. 500-600 700-800 900-1000 1100-1200 Total air necessity lit./min. 200-250 300-350 400-450 500-550 Machine weight kg 30000/32000 33000/34000 38000/40500 43000/45000 *Optional
Since 1978, we are proud of the rightful trust in our machines that have been working successfully in the country and in the world, and we are in an effort to offer you quality.
